47,300 Onwords | Ex-Showroom Chennai
Variants |
Variants | Showroom price | On road price |
Steel wheel | 47300 | 53210 |
Alloy wheel | 49300 | 55460 |
Performance |
Engine | Air cooled, 4-stroke Single Cylinder OHC |
Engine displacement | 110.9 cc |
Maximum Power | 6.0 kW (8 BHP) @ 7500 RPM |
Maximum Torque | 8.70 Nm @ 5500 RPM |
Top speed | - |
Acceleration (0-60Kmph) | - |
Fuel Delivery System | Carburetor |
Cooling | Air cooling |
Ignition | TCI(Transistor Controlled Ignition) |
Compression Ratio | 9.5:1 |
No of Cylinder | 1 |
Bore & Stroke | - |
Spark Plugs Per Cylinder | - |
Valves Per Cylinder | - |
Gear box | Variomatic Drive |
Clutch | Dry, Automatic Centrifugal Clutch |
Starting system | Electric start/Kick start |
Brake |
Front Brake | Internal Expanding Shoe Type (130 mm) |
Rear Brake | Internal Expanding Shoe Type (130 mm) |
ABS | No |
Suspension |
Front Suspension | Bottom Link with Spring-loaded Hydraulic Damper |
Rear Suspension | Swing Arm with Spring-loaded Hydraulic Dampers |
Wheels & Tyres |
Front Tyre | 90/100x10-53 J |
Rear Tyre | 90/100x10-53 J |
Wheel Type | Alloy |
Tubeless Tyres | Yes |
Battery |
Battery Type | MF Batttery |
Capacity | 4.0Ah |
Voltage | 12V |
Instrument Console |
Speedometer | Analouge |
Odometer | Digital |
Engine RPM meter | - |
Fuel Gauge | Analouge |
Lighting |
Head Light | 12V-35W/35W, Halogen bulb |
Tail Light | 12V 5W/21W Multi-Focal Reflector type |
Dimension |
Overall Length | 1769 mm |
Overall Width | 704 mm |
Overall Height | 1161 mm |
Ground Clearance | 155 mm |
Seat Height | - |
Wheelbase | 1238 mm |
Kerb/Wet Weight | 101 kg |
Fuel Tank Capacity | 4.8 litres |
Reserve Fuel Capacity | - |
