57,693 Onwords | Ex-Showroom Chennai
Variants |
Variants | Showroom price | On road price |
DRUM BRAKE | 57693 | 64905 |
DISC BRAKE | 59622 | 67075 |
Performance |
Engine | Air Cooled 4 - Stroke Single Cylinder OHC |
Engine displacement | 124.7 cc |
Maximum Power | 6.72 KW (9.1 Ps) @ 7000 rpm |
Maximum Torque | 10.35 N-m @ 4000 rpm |
Top speed | 90 kmph |
Acceleration (0-60Kmph) | 7.5 secs |
Fuel Delivery System | Carburetor |
Cooling | Air cooling |
Ignition | AMI - Advanced Microprocessor Ignition System |
Compression Ratio | 9.2 : 1 |
No of Cylinder | 1 |
Bore & Stroke | 52.4 x 57.9 mm |
Spark Plugs Per Cylinder | 1 |
Valves Per Cylinder | 2 |
Gear box | 4 Speed constant mesh |
Clutch | Multiplate wet |
Starting system | Self & Kick |
Brake |
Front Brake | 240 mm Dia, Pad - Non Asbestos type |
Rear Brake | Internal expanding shoe type - 130 mm Liners - Non Asbestos type |
ABS | - |
Suspension |
Front Suspension | Telescopic hydraulic shock absorbers |
Rear Suspension | Swing Arm with Hydraulic Shock Absorbers |
Wheels & Tyres |
Front Tyre | 2.75 x 18 - 42 P/4 PR |
Rear Tyre | 3.00 x 18 - 52 P/6 PR |
Wheel Type | Alloy |
Tubeless Tyres | yes |
Battery |
Battery Type | MF battery |
Capacity | 3 Ah |
Voltage | 12 V |
Instrument Console |
Speedometer | Analogue |
Odometer | Analogue |
Engine RPM meter | - |
Fuel Gauge | - |
Lighting |
Head Light | 35 W / 35 W - Halogen Bulb (Multi-Reflector) |
Tail Light | 5 W / 21 W (Multi-Reflector) |
Dimension |
Overall Length | 2005 mm |
Overall Width | 735 mm |
Overall Height | 1070 mm |
Ground Clearance | 150 mm |
Seat Height | - |
Wheelbase | 1265 mm |
Kerb/Wet Weight | 125 Kg (Kick)/ 129 Kg (Self) |
Fuel Tank Capacity | 12 Liter |
Reserve Fuel Capacity | 1.5 Liter |
